Description
The DBEL-ACEM-WH-SDT pairs a compact white enclosure with two LED heads for dependable emergency illumination. Its powder-coated die-cast aluminum housing gives the fixture a clean, durable presence outdoors, while its built-in backup system keeps light available when normal power is interrupted.
Designed for practical installation, the sealed unit provides both a back-plate knockout pattern for wall mounting and a threaded opening for conduit at the top. An included photocell and push-to-test switch make routine operation and checks straightforward.
- • Two 6W LED heads deliver 12W of illumination, backed by a rechargeable NiCd battery.
- • The emergency system is rated for 90 minutes and includes a push-to-test switch with a red status indicator.
- • A built-in photocell is included for light-responsive control.
- • The sealed, gasketed housing is suitable for wet locations from 32°F to 122°F.
- • The fixture accepts 120-277V input and carries a three-year warranty.
Why Choose the DBEL-ACEM-WH-SDT?
This white outdoor emergency unit combines a compact die-cast enclosure, integrated photocell, and 90-minute battery backup in one straightforward fixture. Its wall and conduit mounting provisions help adapt it to the installation, while the sealed construction supports use in wet locations.
Specifications
| UPC | 845060028577 |
| SKU | West-DBEL-ACEM-WH-SDT |
