Description
This LO-PRO junction box and driver combo pairs a 24V OMNIDRIVE electronic-dimmable power supply with a larger enclosure. It delivers up to 96W for compatible low-voltage LED lighting systems.
The driver accepts 90–135VAC at 50/60Hz. For dimmed operation, the connected load must reach at least 60% of the labeled capacity, a key requirement when sizing a lighting system.
- • The combo supplies 24VDC at up to 96W for compatible LED systems.
- • Its LO-PRO enclosure measures 13.5 by 4.5 by 2.38 inches.
- • The driver is Class 2; dimmed installations require at least 60% of labeled load.
Why Choose the DI-TD-24V-96W-LPL?
Choose this driver-and-enclosure combination when a compatible 24V LED system needs electronic dimming and up to 96W of power in a larger LO-PRO format.
Specifications
| UPC | 848333021916 |
| SKU | Diod-DI-TD-24V-96W-LPL |
